Product Summary
The PLL1708DBQ is a low cost, phase-locked loop (PLL) multiclock generator. It can generate four system clocks from a 27-MHz reference input frequency.
Parametrics
Absolute maximum ratings: (1)Supply voltage:4V; (2)Supply voltage differences: 卤0.1V; (3)Ground voltage differences: 卤0.1V; (4)Digital input voltage: 鈥?.3V to (VDD + 0.3)V; (5)Analog input voltage:鈥?.3V to (VCC + 0.3)V; (6)Input current (any pins except supplies):卤10 mA; (7)Ambient temperature under bias:鈥?0鈩?to 125鈩? (8)Storage temperature:鈥?5鈩?to 150鈩? (9)Junction temperature:150鈩? (10)Lead temperature (soldering):260鈩? 5 s; (11)Package temperature (IR reflow, peak):260鈩?
Features
Features: (1)27-MHz Master Clock Input; (2)Zero PPM Error Output Clocks; (3)Low Clock Jitter: 50 ps (Typical); (4)3.3-V Single Power Supply.
Diagrams
<IMG src="http://www.seekic.com/uploadfile/ic-mfg/2011533839269.jpg" border=0>
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 PLL1708DBQ |
Texas Instruments |
Clock Generators & Support Products 3.3V Dual PLL Multi- Clock Gen |
Data Sheet |
|
|
||||||||||||
|
PLL1708DBQG4 |
Texas Instruments |
Clock Generators & Support Products 3.3V Dual PLL Multi- Clock Gen |
Data Sheet |
|
|
||||||||||||
|
PLL1708DBQR |
Texas Instruments |
Clock Generators & Support Products Dual PLL Multi Clock Generator |
Data Sheet |
|
|
||||||||||||
|
PLL1708DBQRG4 |
Texas Instruments |
Clock Generators & Support Products Dual PLL Multi Clock Generator |
Data Sheet |
|
|
||||||||||||
